📦 Package Contents
-
4× solid wood posts
-
Wooden beams and right-angle support brackets
-
Metal roof frame (upper beams, diagonal beams, center connector)
-
Double-tier steel roof panels (lower roof + upper roof)
-
Mosquito-net rails & netting (optional)
-
Hardware kit (screws, nuts, washers)
-
Decorative top finial / cap
-
Installation tools (Allen key, wrench)
🛠 Assembly Steps
Step 1 – Prepare Site & Organize Parts
-
Choose a flat, solid surface with sufficient working space.
-
Lay out all wooden, metal and hardware parts and compare with parts list.
Step 2 – Install Wooden Posts & Bases
-
Position the 4 wooden posts on the ground according to the layout.
-
Secure each post to the ground using anchor bolts or base plates.
-
Make sure posts are vertical and stable (do not fully tighten yet).
Step 3 – Attach Top Wooden Beam Frame
-
Connect the top of the posts using wooden beams to form a square/rectangular frame.
-
Install the right-angle wood brackets at all four corners to reinforce the structure.
Step 4 – Assemble Metal Roof Frame
-
Install the main metal top beams on top of the wooden frame.
-
Add the diagonal beams and central connector to complete the roof skeleton.
-
Tighten screws securely.
Step 5 – Install Lower Steel Roof Panels
-
Starting from one side, place the larger (lower-tier) steel roof panels onto the roof frame.
-
Align each panel and lock them down with screws to ensure a watertight fit.
Step 6 – Install Upper Roof Panels & Top Cap
-
Mount the smaller upper roof frame and steel panels at the center.
-
Finish by attaching the decorative top cap to seal the upper roof.
Step 7 – Install Netting/Curtain (if included)
-
Fix the sliding rails around the inside perimeter of the gazebo.
-
Hang mosquito netting (inner track) and privacy curtains (outer track).
-
Ensure they slide smoothly for opening & closing.
Step 8 – Final Inspection & Anchoring
-
Fully tighten all screws and connection points.
-
Anchor the gazebo firmly using ground stakes, expansion bolts, or extra weights if your location is windy.
✅ Helpful Maintenance Tips
-
Recommended 4+ people for safe and efficient assembly.
-
Routinely check and tighten screws and brackets.
-
Remove snow buildup from roof panels in winter to prevent overload.
-
Apply wood treatment (sealant/oil) periodically to protect wooden posts.
-
Clean metal roof panels using mild soap and water – avoid harsh chemicals.
